MIDEA NUMEN FULL DC INVERTER MSNE-22CRFN8 2.5HP
Product Description
MSNE-22CRFN8 — 2.5 HP
Control
Control type: Remote-controlled
Smart control: Smart Connect App
AI control: AI EcoMaster
Rated Performance
Capacity: 2.5 HP
Type: Full DC Inverter, cooling only
Rated cooling capacity (kJ/h): 23,210
EER (kJ/W·h): 10.80
CSPF: 5.80
Application area (m²): 29–43
Electrical System
Power supply (Ph-V-Hz): 1 Ph–220–240 V–50/60 Hz
Rated input — cooling (W): 2,149
Rated current — cooling (A): 9.34
Refrigerant Type
Refrigerant: R32
Design pressure — liquid/gas (MPa): 4.3 / 1.7
Fan System
Indoor air circulation (m³/h): 1,400 / 1,300 / 960 / 760
Indoor noise level — High/Medium/Low/Silent (dB(A)): 48.5 / 40 / 36.5 / 29
Outdoor noise level (dB(A)): 58
Connecting Pipe System
Connecting pipe — liquid: 1/4 in
Connecting pipe — gas: 1/2 in
Maximum refrigerant pipe length: 30 m
Maximum difference in level: 20 m
Connecting wiring: 4 × 2.5 mm²
Others
Indoor dimensions (W × D × H): 1,055 × 231 × 330 mm
Outdoor dimensions (W × D × H): 805 × 330 × 554 mm
Indoor net/gross weight: 12.1 / 15.6 kg
Outdoor net/gross weight: 27.4 / 29.7 kg
Plug type: No plug
Thermostat type: Remote-controlled
Operation temperature: 17–30°C
PARTS AND SERVICES
1 YEAR
PCB
3 YEARS
COMPRESSOR
10 YEARS
