AVAILABLE
MIDEA AVIGATOR FULL DC INVERTER MSAI-13CRFN8 1.5HP
Product Description
MSAI-13CRFN8 — 1.5 HP
Control
Control type: Wireless remote control
Smart control: Built-in Smart Control
AI control: AI EcoMaster
Rated Performance
Capacity: 1.5 HP
Type: Full DC Inverter, cooling only
Rated cooling capacity (Btu/h): 12,500 (2,798–14,876)
CSPF (Wh/Wh): 5.46
Energy Star: 5-Star
Electrical System
Power supply (V-Hz-Ph): 220–240 V~, 50 Hz, 1 Ph
Rated power input (W): 1,100 (180–1,390)
Rated running current (A): 4.9 (1.5–6.2)
Refrigerant Type
Refrigerant/charge: R32 / 420 g
Design pressure — liquid/gas (MPa): 4.3 / 1.7
Fan System
Indoor air circulation (m³/h): 625
Indoor noise level — High/Medium/Low (dB(A)): 38 / 31.5 / 29
Outdoor noise level (dB(A)): 54
Connecting Pipe System
Connecting pipe — liquid: 1/4 in
Connecting pipe — gas: 3/8 in
Maximum refrigerant pipe length: 25 m
Connection wiring: 4 × 1.5 mm²
Others
Indoor dimensions (W × D × H): 813 × 201 × 289 mm
Outdoor dimensions (W × D × H): 720 × 270 × 495 mm
Indoor net/gross weight: 8.5 / 10.8 kg
Outdoor net/gross weight: 19.6 / 21.4 kg
Application area: 150–230 sq. ft.
Thermostat type: Remote-controlled
Plug type: No plug
Operation temperature: 17–30°C
Connecting Pipe System
Connecting pipe — liquid: 1/4 in
Connecting pipe — gas: 3/8 in
Maximum refrigerant pipe length: 25 m
Connection wiring: 4 × 1.5 mm²
Others
Indoor dimensions (W × D × H): 813 × 201 × 289 mm
Outdoor dimensions (W × D × H): 720 × 270 × 495 mm
Indoor net/gross weight: 8.5 / 10.8 kg
Outdoor net/gross weight: 19.6 / 21.4 kg
Application area: 13–20 m²
Thermostat type: Remote-controlled
Plug type: No plug
Operation temperature: 17–30°C
PARTS AND SERVICES
1 YEAR
PCB
3 YEARS
COMPRESSOR
10 YEARS
