MIDEA AVIGATOR FULL DC INVERTER MSAI-19CRFN8 2.0HP
Product Description
MSAI-19CRFN8 — 2.0 HP
Control
Control type: Wireless remote control
Smart control: Built-in Smart Control
AI control: AI EcoMaster
Rated Performance
Capacity: 2.0 HP
Type: Full DC Inverter, cooling only
Rated cooling capacity (Btu/h): 18,500 (2,800–19,970)
CSPF (Wh/Wh): 5.27
Energy Star: 5-Star
Electrical System
Power supply (V-Hz-Ph): 220–240 V~, 50 Hz, 1 Ph
Rated power input (W): 1,688 (244–2,040)
Rated running current (A): 8.46 (1.6–9.41)
Refrigerant Type
Refrigerant/charge: R32 / 720 g
Design pressure — liquid/gas (MPa): 4.3 / 1.7
Fan System
Indoor air circulation (m³/h): 895
Indoor noise level — High/Medium/Low (dB(A)): 44 / 37.5 / 34
Outdoor noise level (dB(A)): 56
Connecting Pipe System
Connecting pipe — liquid: 1/4 in
Connecting pipe — gas: 1/2 in
Maximum refrigerant pipe length: 30 m
Maximum difference in level: 20 m
Connection wiring: 4 × 2.5 mm²
Others
Indoor dimensions (W × D × H): 975 × 218 × 308 mm
Outdoor dimensions (W × D × H): 765 × 303 × 555 mm
Indoor net/gross weight: 10.9 / 14.4 kg
Outdoor net/gross weight: 25.1 / 27.8 kg
Application area: 200–300 sq. ft.
Thermostat type: Remote-controlled
Plug type: No plug
Operation temperature: 17–30°C
PARTS AND SERVICES
1 YEAR
PCB
3 YEARS
COMPRESSOR
10 YEARS
