AVAILABLE
KOLIN PRIMUS GOLD KSG-IW10WFY-8K1M32 1.0HP
Product Description
KSG-IW10WFY-8K1M32 — 1.0 HP
Rated Performance
Nominal capacity: 1.0 HP
Rated cooling capacity (kJ/h): 10,440 (1,080–11,484)
CSPF: 7.31
Energy Star: 5-Star ⭐⭐⭐⭐⭐
EER: 15.5 kJ/hW (17–14)
Suitable area: 12–18 m²
Electrical System
Power supply (Ph-V-Hz): 1 Ph / 230 V / 60 Hz
Rated current — cooling (A): 3.7
Rated input — cooling (W): 675 (135–810)
Refrigerant Type
Refrigerant/charge: R32 / 570 g
Fan System
Indoor air circulation (m³/h): 700 / 630 / 560 / 490
Indoor noise level — High/Medium/Low (dB(A)): 42 / 38 / 36
Outdoor air circulation (m³/h): 1,950
Outdoor noise level (dB(A)): 50
Connecting Pipe System
Connecting pipe — liquid/high side: Ø 1/4 in
Connecting pipe — gas/low side: Ø 3/8 in
Maximum pipe height: 10 m
Maximum pipe length: 20 m
Circuit breaker: 20 A
Others
Net dimensions (W × D × H) — indoor: 888 × 215 × 293 mm
Net weight — indoor: 10.5 kg
Packing dimensions (W × D × H) — indoor: 935 × 349 × 273 mm
Gross weight — indoor: 12.5 kg
Net dimensions (W × D × H) — outdoor: 731 × 300 × 555 mm
Net weight — outdoor: 24 kg
Packing dimensions (W × D × H) — outdoor: 791 × 373 × 590 mm
Gross weight — outdoor: 26.5 kg
PARTS AND SERVICES
1 YEAR
PCB
3 YEARS
COMPRESSOR
10 YEARS
