Description

KS-IW10-GPAI13P1M32 — 1.0 HP
Control

Control type: Remote control
Smart control: EWPE Smart App / Wi-Fi

Rated Performance

Rated cooling capacity (kJ/h): 10,010 (3,003–11,011)
CSPF (W/W): 7.04
Energy Star: 5-Star
Suitable area: 11–17 m²

Electrical System

Power supply (Ph-V-Hz): 230 V–60 Hz, 1 Ph
Rated input — cooling (W): 562 (112–674)
Rated current — cooling (A): 3.6
Maximum input / rated power (W): 1,200
Maximum current / rated current (A): 7.5

Refrigerant Type

Refrigerant/charge: R32 / 420 g

Fan System

Indoor air circulation (m³/h): 600 / 470 / 350
Indoor noise level — High/Medium/Low (dB(A)): 38 / 34 / 26
Outdoor air circulation (m³/h): 1,950
Outdoor noise level (dB(A)): 49

Connecting Pipe System

Connecting pipe — high side: 1/4 in
Connecting pipe — low side: 3/8 in
Maximum pipe length: 20 m
Maximum height difference: 10 m
Circuit breaker: 15 A

Others

Net dimensions (W × D × H) — indoor: 907 × 200 × 292 mm
Net weight — indoor: 22.5 kg
Packing dimensions — indoor: 965 × 371 × 273 mm
Gross weight — indoor: 25.0 kg

Net dimensions (W × D × H) — outdoor: 732 × 330 × 555 mm
Net weight — outdoor: 22.5 kg
Packing dimensions — outdoor: 794 × 376 × 615 mm
Gross weight — outdoor: 25.0 kg
