KOLIN CERTUS AI WALL MOUNTED INVERTER KS-IW15-MCAI12O1M32 1.5HP

KS-IW15-MCAI1201M32 — 1.5 HP

Control
Control type: Wireless remote control
Smart control: Smart Controller / Wi-Fi

Rated Performance
Type: Cooling only
Rated cooling capacity (kJ/h): 12,880 (3,864–14,168)
CSPF (W/W): 5.80
Energy Star: 5-Star ⭐⭐⭐⭐⭐
EER (kJ/hW): 10.73
Suitable area (m²): 15–20

Electrical System
Power supply (Ph-V-Hz): 230 V–60 Hz, 1 Ph
Rated input — cooling (W): 1,200 (240–1,440)
Rated current — cooling (A): 5.09 (1.6–5.45)

Refrigerant Type
Refrigerant/charge: R32 / 0.42 kg

Fan System
Indoor air circulation (m³/h): 665 / 560 / 420
Indoor fan type: Cross-flow
Outdoor fan type: Propeller fan
Outdoor air circulation (m³/h): 1,300

Connecting Pipe System
Connecting pipe — gas: 3/8 in
Connecting pipe — liquid: 1/4 in
Maximum pipe length: 25 m
Maximum elevation: 10 m

Others
Indoor sound level — Hi/Mi/Lo: 31/29/22 dB(A)
Outdoor sound level: 55 dB(A)
Net dimensions (W × H × D) — indoor: 813 × 289 × 201 mm
Net dimensions (W × H × D) — outdoor: 668 × 469 × 252 mm
Net weight — indoor: 7.8 kg
Net weight — outdoor: 17 kg
Packing dimensions — indoor: 870 × 360 × 270 mm
Packing dimensions — outdoor: 765 × 515 × 270 mm
Gross weight — indoor: 10.2 kg
Gross weight — outdoor: 18.5 kg

PARTS AND SERVICES
1 YEAR
PCB
3 YEARS
COMPRESSOR
10 YEARS
