LG APX3 NEW DELUXE MODEL SPLIT TYPE HSN/HSU-24APX3 2.5HP
Product Description
HSN24IPX3 / HSU24IPX3 — 2.5 HP
Control
Control type: Remote control
Rated Performance
Type: Cooling only
Rated cooling capacity (kJ/h): 22,000
CSPF (W/W): 5.95
EER (Btu/h)/W: 11.00
Electrical System
Voltage range (V): 230
Power supply (Ph-V-Hz): 230 V–60 Hz, 1 Ph
Rated input — cooling (W): 2,000
Maximum input (W): 2,000
Refrigerant Type
Refrigerant/charge: R32
Fan System
Indoor fan type: Cross-flow
Outdoor fan type: Propeller fan
Outdoor fan motor type: BLDC
Connecting Pipe System
Connecting pipe — gas: 1/2 in
Connecting pipe — liquid: 1/4 in
Connecting wiring (equipped): 4 × 1.5 mm²
Others
Net dimensions (W × H × D) — indoor: 895 × 307 × 235 mm
Net dimensions (W × H × D) — outdoor: 870 × 650 × 330 mm
Net weight — indoor: 11 kg
Net weight — outdoor: 41 kg
Packing dimensions (W × H × D) — indoor: 967 × 383 × 296 mm
Packing dimensions (W × H × D) — outdoor: 1,040 × 710 × 455 mm
Gross weight — indoor: 13 kg
Gross weight — outdoor: 41 kg
PARTS AND SERVICES
1 YEAR
COMPRESSOR
10 YEARS
