LG APX3 NEW DELUXE MODEL SPLIT TYPE HSN/HSU-09APX3 1.0HP
Product Description
HSN09IPX3 / HSU09IPX3 — 1.0 HP
Control
Control type: Remote control
Rated Performance
Type: Cooling only
Rated cooling capacity (kJ/h): 9,812
CSPF (W/W): 5.50
EER (Btu/h)/W: 11.48
Electrical System
Voltage range (V): 187–276
Power supply (Ph-V-Hz): 230 V–60 Hz, 1 Ph
Rated input — cooling (W): 810
Maximum input (W): 810
Refrigerant Type
Refrigerant/charge: R32 / 450 g
Fan System
Indoor fan type: Cross-flow
Outdoor fan type: Propeller fan
Outdoor fan motor type: AC
Connecting Pipe System
Connecting pipe — gas: 3/8 in
Connecting pipe — liquid: 1/4 in
Connecting wiring (equipped): 4 × 1.0 mm²
Others
Net dimensions (W × H × D) — indoor: 799 × 307 × 235 mm
Net dimensions (W × H × D) — outdoor: 717 × 495 × 230 mm
Net weight — indoor: 10.2 kg
Net weight — outdoor: 19.6 kg
Packing dimensions (W × H × D) — indoor: 871 × 383 × 396 mm
Packing dimensions (W × H × D) — outdoor: 839 × 532 × 324 mm
Gross weight — indoor: 11.5 kg
Gross weight — outdoor: 21 kg
PARTS AND SERVICES
1 YEAR
COMPRESSOR
10 YEARS
